ARB Air Locker’s patented design has proven to be an ultra-dependable product, even under the most arduous conditions. It’s strength lies within the simplicity of the design, the minimal the moving parts ensures maximum reliability. All structural components are manufactured from aerospace grades of high alloy steel, and where possible, they have increased the number of differential pinion gears to distribute torque loads evenly. Many recent Air Locker designs also utilize timed gear sets to further improve strength, a design feature that has led to a second US patent on the product.

The ARB air locker differential is made from aerospace-grade high alloy steel for the ultimate in strength and durability. It is designed with simplicity in mind and features few moving parts for added reliability. This air locker differential provides excellent traction control both on the street and on the trail, so your Jeep can power through harsh road or weather conditions.

Please Note: This is not a direct fit to any OE applications.

The Eaton Elocker has been designed to handle a variety of assignments. Anything from towing, rock climbing, and everything in between. This has been a popular component among the 4x4 community for its smooth operation and reliable strength. These are available for both front and rear axles, and you will notice improvements in both traction, and maneuverability.

These are controlled though a flip of a switch. When in the “off” position, the differential will be fully-open. When activated into the “on” position, the electronic mechanism will lock the internal differential gear case providing 100% axle lock.

Other features include:
•    Push-button operation.
•    Designed with four (4) alloy pinion gears to withstand high levels of torque.
•    Net forged gears provide greater strength over competitors machine-finished gears.
•    Locking collar is timed for smooth, consistent engagement.

Please note that  the 2007+ JK uses the 3.73 & down carrier because of thick gears.

Part numbers:
•    3.73 and down gear ratio – 19977-010
•    3.92 and up gear ratio – 19969-010

NOT FOR RUBICON HOUSINGS

The Eaton Detroit Truetrac Differential Dana 44 30 Spline 3.73 and Down is a helical-gear style performance differential that incredibly maximizes wheel traction. It also enhances driving as well as handling characteristics. It allows a single wheel to spin slower or faster as necessary. The Eaton Detroit Truetrac Differential is automatic, quiet and smooth. The unit engage without any driver action or knowledge required. The Eaton Detroit Truetrac Differential has no wearable part and needs no maintenance.

Provide some added traction to your off-road vehicle when you install the Eaton Dana 44 Performance Differential. Designed to help prevent the gears from slipping while driving on wet or slippery roadways. The Eaton 44 Performance Differential is easy to install with basic tools. The improved 4 pinion spyder gear allows added strength for more heavy duty applications and is used with 30 spline axles.

*Will not work with 2013-2016 JK's with automatic transmissions.

Yukon Grizzly locker, fits Dana 44, 30 spline, 3.73 & down.

Fits Dana Spicer 44 with 30 spline axles 3.73 and down ratio only Patented internal design reduces common locker failures 8620 internals for added strength Assembled in the USA The Yukon Grizzly Locker is the ultimate in mechanical locking differentials for street, off-road, and drag racing. Grizzly Lockers provide 100% power to both tires, while still allowing for disengagement while negotiating turns.

Technical Notes: This unit is drilled for 7/16" ring gear bolts. If you are using it in an application which has 3/8" ring gear bolts, please purchase qty 10 of part number YSPBLT-027 to sleeve the ring gear bolts.

The Yukon Zip Locker is the latest in on-demand traction. Its air-operated design allows you to switch from an open differential to 100% lockup when you need it, giving you the ultimate in driver selectability. The Yukon Zip locker is an air operated locker that provides selectable traction for off road or street use. This unit features 4320 Chrome Moly internals for added strength. Assembled in the USA! compressor sold separately. All Zip Lockers are backed by the best warranty in the business! Yukon covers the replacement unit and covers any collaterally damaged parts and associated labor, up to $2,000!

Note: Fits DynaTrac Pro Rock 44 only.

The Yukon Gear and Axle Dana 44 install kit is available for those of you looking to perform an overhaul, and need all the required components to get the job done.

This kit includes everything to perform an overhaul. The components include but are not limited to Timken bearings, pinion nut, the required shims, and the required hardware to make for a ready installation.

The Yukon Gear and Axle Dana Master Overhaul install kit is available for those of you looking to perform an overhaul, and need all the required components to get the job done.

This kit is available for those with the Eaton E-locker, or open carrier.

This kit includes everything to perform an overhaul. The components include but are not limited to Timken bearings, pinion nut, the required shims, and the required hardware to make for a ready installation.

Ball joints wear out and break, reducing your steering feel and precision or perhaps leaving you stranded on the side of the road. When you are thinking about replacing your ball joints, make sure you choose one that is of the highest quality. The Dana Spicer Ball Joint Kit will give you long lasting performance so you can hit the road or trail with confidence.

Note – Fits Dana 30 and Dana 44 front axles.

Dynatrac ProSteer Heavy-Duty BallJoints™ are the strongest ball joints for the Jeep Wrangler JK, and the only ones that are rebuildable, making them the last set of ball joints you’ll ever need to purchase!

Dynatrac ProSteer Heavy-Duty BallJoints™ feature:
•    US-made, Precision-ground stainless steel spherical ball
•    US-made, Heat-treated Chromoly steel stem
•    US-made, High-strength billet steel body
•    Patented and exclusive, vertical impact ball stem travel arrestors
•    Teflon-coated friction surfaces to reduce wear and extend ball joint life
•    Specially designed grease seals prevent contamination of the internal area
•    Grease fittings that allow for regular greasing of the internals.

Dynatrac ProSteer Heavy-Duty BallJoints™ rebuildable design allows you rebuild the ball joints without having to spend time and money on pressing the ball-joints out of the axle housing. This reduces wear and tear on the housing ends, along with significantly reducing downtime for servicing.

No other ball joint is designed to withstand the rigorous demands of the off-road environment like Dynatrac Heavy-Duty BallJoints™. Dynatrac ProSteer Heavy-Duty BallJoints™ are the only aftermarket ball joint 100% made and assembled in America, They’re an upgrade every JK owner should have on their rig.

The TeraFlex Dana 30/44 Heavy Duty Ball Joint Set has been designed to handle the increased stress caused by either oversized tires, or offset wheels. This is achieved because the upper ball joint incorporates hard sintered wear bushings to handle heavy side load demands without failure.

The lower ball joint has been designed with a threaded top cap for adjustable pre-load, and it allows grease servicing without removing the axle shaft, even with larger RCV shafts.  These ball joints also feature a machined grease passage in the lower joint housing in the lower joint housing assembly which provides further lubrication access without affecting the ball joint load surface.

Additional features include:
•    1045 carbon steel housing with magnesium phosphate coated assembly
•    4140 chromoly ball/stud with magnesium phosphate anti-corrosion coating
•    Factory style serrated flanged castle nut
•    CR black neoprene boot

These ball joints will fit all JK Dana 30 and Dana 44 axles.

Does not fit Dynatrac ProRock Housing

*SOME 2012 and ALL newer Jeep Wranglers come factory with larger front axle shafts (Dana 30 & 44) than previous years, and will require grinding on the stub shaft forging parting line for clearance.

CLICK HERE FOR INSTALL INSTRUCTIONS

The Ten Factory D44-456JKF Pinion Set is available for the serious off-road enthusiast. Motive Gear is one of the leaders in gear and pinion technology due to the build quality of their products. Their gear sets are trusted by off-road enthusiasts in a world wide spectrum due to the delivery and performance.
Here are additional specs of the D44-456JKF set:

• 4.56:1 Ring and pinion ratio
• 24 Pinion spline count
• Standard ring gear rotation
• 41 Ring gear teeth
• 8.500” Ring gear diameter
• 1.376” Pinion shaft diameter
• 9 Pinion gear teeth

The Ten Factory D44-488JKF Pinion Set is available for the serious off-road enthusiast. Motive Gear is one of the leaders in gear and pinion technology due to the build quality of their products. Their gear sets are trusted by off-road enthusiasts in a world wide spectrum due to the delivery and performance.
Here are additional specs of the D44-488JKF set:

• 4.88:1 Ring and pinion ratio
• 24 Pinion spline count
• Standard ring gear rotation
• 39 Ring gear teeth
• 8.5” Ring gear diameter
• 1.376” Pinion shaft diameter
• 8 Pinion gear teeth

The Ten Factory D44-513JKF Pinion Set is available for the serious off-road enthusiast. Motive Gear is one of the leaders in gear and pinion technology due to the build quality of their products. Their gear sets are trusted by off-road enthusiasts in a world wide spectrum due to the delivery and performance.
Here are additional specs of the D44-513JKF set:

• 5.13:1 Ring and pinion ratio
• 24 Pinion spline count
• Standard ring gear rotation
• 41 Ring gear teeth
• 8.500” Ring gear diameter
• 1.376” Pinion shaft diameter
• 8 Pinion gear teeth

The Ten Factory D44-538JKF Pinion Set is available for the serious off-road enthusiast.  Motive Gear is one of the leaders in gear and pinion technology due to the build quality of their products. Their gear sets are trusted by off-road enthusiasts in a world wide spectrum due to the delivery and performance.
Here are additional specs of the D44-538JKF set:

•    5.38:1 Ring and pinion ratio
•    26 Pinion spline count
•    Standard ring gear rotation
•    43 Ring gear teeth
•    8.5” Ring gear diameter
•    1.376” Pinion shaft diameter
•    8 Pinion gear teeth

The Adams Driveshaft Super Dana 44 is available for separate purchase for those of you who need to replace a worn or damaged unit, or if you’re building a custom driveline.

These are very strong, and fabricated from high grade metals to provide the user with the reliability needed for the increased power, or larger tires added on the vehicle.



**This yoke fits JK Dana 30 and Dana44 axles. 1310 yoke is NOT an O.E replacement**

The Adams Driveshaft Rear Pinion Yoke comes ready installation. These are perfect for those who need to replace a worn, or damaged yoke designed to meet or exceed OEM build quality. This pinion yoke will work with 1350 series driveshafts, and will provide more strength and reinforcement to the driveline.

The Spicer Drivetrain Components Companion Flange Assembly is available for those who need to replace a worn, or damaged companion flange. Spicer Drivetrain Components manufactures parts that meet or exceed the demands of OEM build quality to provide the consumer with a reliable component they can depend on.

The Companion Flange Assembly has been fabricated from high-grade metals, and comes ready to install.

The Dana Spicer U-bolt kit is available for those who are performing maintenance on the differential, and need to replace worn, or misplaced hardware.
This includes a pair of u-bolts along with washers and nuts.

Here is a list of what differentials this U-bolt kit will work with:

•    Dana 30
•    Dana 44
•    GM 8.2”
•    12P
•    12T
•    M20

Series: 1210/1310/1330 Thread Dia: .312-24 C/L to C/L: 1.416 Bearing cap diam: 1.062” Nut Torque (lb.ft) 14-17

The Dana Spicer U-bolt kit is available for those who are performing maintenance on the differential, and need to replace worn, or misplaced hardware. This includes a pair of u-bolts along with washers and nuts.

Use the RCV Performance Ultimate CV axles for replacement of the Dynatrac ProRock 44 u-joint axle shafts. Tests show the Ultimate CV axles to be 2X stronger than OEM axle shafts. They remain tough at straight and extreme angles important where the u-joints are the weakest.

The axles allow for the smooth transfer of power to the ground by eliminating the binding of the u-joint. Works with large tires and vast amounts of power. Low maintenance with use off road or used on the street. Ultimate CV axles are backed with a lifetime limited warranty.

This axle set is complete with right and left CV axle shafts, instructions, hardware, outer stubs, synthetic moly grease and SST seals. The standard coating is black oxide for corrosion resistance and important for salty roads. Use the custom axle configuration form or contact us for details.

The Motive Gear Front D44 Pro Rock U-Joint Axle Kit has been designed to be a strong set of axles designed and built to handle the rugged environments. They are composed of 4340 Forged Chromoly Alloy steel and coated with black oxide to ensure axle strength when under intense load and resistant to the elements. If you have upgraded to the ProRock 44 system and want a durable set of axles to go with it, these axles are a perfect option for you.





The RCV Performance Ultimate Dana 44 CV Axle Set has been built to provide superior reliability and performance when compared to the factory U-joint style axles in your vehicle. These are built to be high strength axles even in extreme angles, and are built to handle larger wheels and tires.

Included with the RCV Performance Ultimate Dana CV Axle Set are SST seals with an installation tool, installation instructions, synthetic moly grease, and hardware for installation. Black Oxide coating is standard on these particular shafts for protection against corrosion.

The Rancho® High-Steer Knuckles maintain steering geometry and add strength to the most vulnerable points within the steering envelope when off-road driving. The knuckles add an additional 1.5-inches of clearance within the tight space, helping to protect critical steering components, and their design also helps lift the steering linkage out of range from direct impact from off-road obstacles or impediments. The High-Steer Knuckles are precisely engineered and heavy-duty for Left Hand and Right Hand Drive, 3-inch and higher lifted Jeep Wrangler JK’s. The kit includes: a front left High-Steer Knuckle, a front right High-Steer Knuckle and 3-inch bump stops. This product offers a Limited Lifetime Warranty. A 3-inch Track Bar Relocation Bracket is required and is sold separately if your lift does not have one (RS62101). A flipped drag link is also required and is sold separately.

Fits JK Dana 30, JK Rubicon Dana 44

Adds critical strength and height to off-road JK’s

Aligns the geometry of the track bar and drag link to reduce bump steer

Constructed from high-strength steel

Compatible for left- and right-hand drive models

Limited Lifetime Warranty

Requires use of 3-in. track bar mount – (sold separately)

Requires use of a flip drag link – (sold separately)

The Reid 30/44 Left Side Steering Knuckle is designed for Dana 30/44 axles and are heavy duty stock replacement knuckles. Raised steering linkage, dual steering stops, and increased strength are a few of the key improvements made to these Jeep JK steering knuckles. The design allows for the OEM outers to be reused, which simplifies installation. The assembly uses stock brake rotors, calipers, stub shafts and U-joints and fits Mopar and aftermarket axles, as well. No machining is required for installation, allowing for the easy, bolt on install that off roaders have come to expect from Reid products. Aftermarket high strength axle shafts, U-joints/CV joints, and stub shafts can be used and the steering knuckle renders antilock brakes, traction control, and electronic stability control systems fully operational. The 30/44 steering knuckle allows the steering linkage to be raised significantly while retaining clearance for OEM Jeep and most aftermarket wheels. With installation of the steering knuckles, the tie rod gains 1.5 inches of clearance to minimize vulnerability to trail damage. When the drag link is flipped, the rig gains 3 inches of height to perfectly correct the steering geometry necessary to accommodate the typical 3-4 inch suspension lift. Requires an aftermarket drag link, and we recommend a track bar bracket to eliminate bump steer. The Reid steering knuckle is cast from high strength ductile iron and is beefed up with extra material and ribbing. Cast-in dual steering prevents bent stop bolts that can result in u-joint and axle failures. Tapered tie rod holes accept heavy duty one ton tie rod ends that are commonly used in most aftermarket steering linkage. Factory tie rod ends may require slight modification. The knuckle is powder coated bright orange for long lasting looks.

The Reid Dana 30 and Dana 44 Steering Knuckles are super heavy duty knuckles designed to replace your factory knuckles. The Reid knuckles feature raised steering linkage, as well as duel steering stops.  These are a complete bolt-on design to allow your factory antilock brakes, Electronic Stability Control systems, as well as your Traction Control to remain fully operational.

These have also been designed to accept aftermarket high strength axle shafts and U-Joints/CV joints. The steering linkage has been designed to be raised to accommodate aftermarket wheels.  And the clearance for the tie rods gain a 1.5 inch advantage.

For those of you with a 3-4 inch suspension lifts, you will find that the drag link on Reid Knuckles have been flipped for a gain of 3 inches. This improves the steering geometry which allows minimal steering correction for taller lift kits. Aftermarket drag link is required, and a track bar bracket is recommended to eliminate bump steer.

These have been crafted out of high strength ductile iron, and the cast-in dual steering stops are designed to prohibit bent stop bolts that can cause u-joint and axle failures. Lastly these have been powder-coated bright orange for years of protection against corrosion.

Equip your vehicle with this heavy-duty front track bar bracket from Synergy Manufacturing. This bracket centers the track bar near the axle centerline and raises the suspension roll center by up to three inches. This helps to reduce body roll, offering a smoother driving experience and better overall handling. The bracket can be trimmed to accommodate track bars up to three inches over stock height. This high-strength steel bracket is designed to be welded on for additional strength and durability.

CLICK HERE FOR INSTALL INSTRUCTIONS

The RCV Performance Dana 44 Axle Tube Seals provide the ultimate protection when it comes to keeping the elements such as dirt, and grime out of your axle tubes. This kit cimes with a pair of re-buildable tube seals, each of which has 3 O-ring seals on the outer, and 2 washer seals on the inner.

Rebuilding these tube seals is simple, and they provide easy access to the zerk fittings which are located on the sides to inject grease.  Lastly, they come in an anodized red finish for anti-corrosion resistance.

NOTE: Color may vary (Red, Orange, or Silver)

If you’re in the market for a lightweight, on-board air compressor system, then have a look at this unit from ARBThis is ARB’s Compact On-Board Air Compressor Kit. This kit features a lightweight design that is simple to use and install. Perfect to use in rock crawlers, or for use in your daily driver who are fans of compact designs.

This is a fully-sealed compressor, that features a pressure switch controlled manifold system, as well as a hard anodized cylinder bore, with carbon fiber piston rings.

Easily operation allows the user to power this compact compressor into their 12 volt accessory supply in most vehicles with 12 volt and 24 volt systems.

This is a permanently mounted air compressor which includes a full wiring loom. You will also find mounting hardware with a reinforced bracket along with an isolating switch will be included. This compressor can be used to activate air lockers, and can perform other functions such as inflating camping gear.

This air compressor is compact enough to fit into the tightest of spaces, and it is even quiet enough to fit inside the cab. It has enough output to air up four 35 inch to 37 inch tires in a single duty cycle, and typically can air up a 35 inch tire in just over two minutes.

Kit includes:

•    Full assembled and bench tested air compressor
•    Complete wiring loom with Air Locker solenoid plug-in contacts
•    OEM quality compressor isolating swtich
•    Relocatable splash resistant air filter washable high-flow sintered bronze filter cartridge
•    Mounting hardware with reinforcing backing plate
•    Comprehensive photo illustrated installation guide

This is ARB’s twin on-board compressor. These kits have been designed to be compact in size, yet provide a high volume compressed air source to suit the needs of most air powered tools while controlling the needs of the ARB Air Locker.
With reliability in mind, the ARB Compressor Kits are crafted out of light weight, high strength engineering grade materials which include military and aerospace standard components. All components are sealed which promotes moisture and dust resistance when you’re on extreme terrains.

Here is what’s included in the kit:
•    Fully assembled and tested air compressor.
•    Complete wiring loom with air locker solenoid plug-in terminals.
•    OEM quality compressor isolating switch.
•    2 relocatable splash resistant air filters with washable high flow sintered bronze filter cartridges.
•    Mounting bolts and washers.
•    Photo illustrated installation guide.
